20KHz-200KHz Ultrasonic Automation Power Supply Ultrasonic Generator Variable Frequency Ultrasonic Cleaning Generator

Category：Company news

20KHz-200KHz Ultrasonic Automation Power Supply Ultrasonic Generator Variable Frequency Ultrasonic Cleaning Generator

Industrial ultrasonic cleaning generator is a widely used equipment in the industrial field, which utilizes the vibration effect of ultrasound to efficiently clean the surface of objects. Industrial ultrasonic cleaning generator is a device that uses the explosive effect of small bubbles generated by ultrasonic waves in liquids to clean the surface of objects. When ultrasound acts on a liquid, it generates high-frequency vibrations in the liquid, causing changes in the interaction forces between liquid molecules and forming tiny bubbles. These bubbles rapidly expand and explode under the action of ultrasound, generating strong impact and jet force, thereby cleaning the dirt and impurities on the surface of the object.

Type	Power(W)	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
PLS-QXDY-300	300W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
PLS-QXDY-600	600W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
PLS-QXDY-900	900W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
PLS-QXDY-1000	1000W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
PLS-QXDY-1200	1200W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
PLS-QXDY-1500	1500W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
PLS-QXDY-1800	1800W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
PLS-QXDY-2000	2000W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
PLS-QXDY-2400	2400W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
PLS-QXDY-3000	3000W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	54KHZ,60KHZ,68KHZ,70KHZ,80KHZ,100KHZ,120KHZ,135KHZ
High Frequency	100W-300W	175-200KHZ
Above ultrasonic generator 110V-120V or 220V-240V are available,contact with us during your order with detail request

20KHz-200KHz Ultrasonic Automation Power Supply Ultrasonic Generator Variable Frequency Ultrasonic Cleaning Generator
